Overview
The LMDS0602-2A1 is a 2-phase dual axis linear stepper motor that generates a continuous force of 1.5 lbs [6.7 N]. Integral air bearings are used to maintain the required motor air gap. 60 PSI of filtered compressed air should be supplied by the customer. Air is supplied to the motor via a 0.25″ diameter air hose inlet. Power is supplied to the motor via a 9-pin D-Sub Male connector. There are mounting holes on the top of forcer to allow for payload mounting.
To determine your motion profile needs, use our linear motion calculator.
Datasheet
Full specifications and performance data
